RN90-110 Series

Wheeled Tractor

RN90-110 Series

Applicable to both paddy field and dry field

90/110 HP Four-cylinder high-pressure common-rail engine

Fuel atomization effect is good, more fuel-efficient

16F+8R Meshing sleeve gearshift

Optional paddy tyre

435mm ground clearance

Hydraulic-driven steering system

The rear track is adjustable

Get Pricing

Manual Download

Advantage introduction

16F+8R Transmission box
Two-speed power output options
Strong pressure lifter, with single and double action switch, CAT II suspension system
Full hydraulic steering system with independent oil circuit

More Advantages

Param

Model	Unit	RN904Pro/RN1104Pro
Overall dimensions (L×W×H)	mm	4600×2095×2950
Wheelbase	mm	2350
Min. operating mass	kg	4300
Min. ground clearance	mm	435
Engine emission	/	National Ⅲ
Calibration power	kW	66/81
Fuel consumption rate	g/kW•h	≤250
Clutch type	/	Dual action of dry type and independent control
Number of gears	/	16F+8R meshing sleeve shift
Brake mode	/	Wet type and disc type
Tire specification	/	12.4-24/16.9-34
(front wheel/rear wheel)	/	12.4-24/16.9-34
Type of hydraulic lifting system	/	Semi-split lifter
Max. pull force	kN	≥25
Tillage depth control method	/	Position adjustment and floating control
Hydraulic-output multiway valve	/	3-group hydraulic output
Maximum flow of hydraulic output	L/min	64
Hydraulic hitching mechanism	/	Three-point rear hitching: TypeII.
Calibration traction force	kN	34.5/35.5
PTO power output	kW	56.3/69
PTO speed	r/min	540/1000
Safety shelf or cab	/	A/C cab
