The high-pressure common rail turbocharged engine of YUCAI is adopted which is powerful, economical and reliable.
The independently operated 14-inch (RG1804) 15-inch (RG2104) heavy-duty double-acting clutch adopts imported friction material for high torque reserve and reliability;
The forced cooling lubrication can effectively prevent overheating of the transmission system, ensure the normal lubrication of key parts such as gears and bearings, guarantee the service life of seals and lubricating oil, and greatly improve the reliability of the transmission system;
The mechanical self-boosting brake is matched with hydraulic control and can automatically compensate wear and tear, which is reliable, safe and light.
Powerful tool for deep ploughing, mainstay of ZOOMLION
Powerful & reliable
Comfortable driving & easy operation
Excellent performance and high operation efficiency
Model | Unit | RG1804/2004 |
Overall dimension (L×W × H) | mm | 5280×2230×3060 |
Wheelbase | mm | 2720 |
Minimum mass during operation | kg | 6015 |
Minimum ground clearance | mm | 500 |
Engine emission | / | National Emission Standard III |
Rated power | kw | 132.6 |
Fuel consumption rate | g/kW•h | ≤237 |
Cluth type | / | The double-acting clutch adopts imported friction material, comes standard with clutch control system with hydraulic assistant |
Number of gears of the gearbox | / | 16F+16R |
Tyre size (front wheel / rear wheel) | / | 14.9-28/18.4-38 |
Type of hydraulic lifting system | / | Split type |
Maximum lifting capacity | KN | 40 |
Tillage control method | / | Position control, height control, forced control |
Hydraulic output multiway valve | / | 3 groups |
Hydraulic hitch | / | Three-point rear suspension,category III |
Traction force | KN | 56 |
PTO output power | kW | 113 |
Power output speed | r/min | 540/1000 |
Safety shelf or cab | / | Air-conditioned cab |
